INMAR 530-PT-HD (17' 8") Patrol Series Inflatable Boat + DF40ATL Motor
INMAR 17' 8" DF40ATL package deal boat outboard, military, patrol, search and rescue, Inflatable



Alternative Views:


M.S.R.P. $11,666.90

Product Code: 530-PT-HD-DF40ATL
Qty:

Description

BOAT
Specifications:
  • Length 17' 8"
  • Beam 7' 2"
  • Weight w/ floor: 340 lbs.
  • Weight capacity: 12 persons / 2,985 lbs.
  • Max HP / Weigh: 60 HP / 250 lbs / Long shaft (20")
  • Recommended HP: 40 HP
  • Tube diameter 22" (Separate air chambers 5 + 1)
  • Fabric: Mehler
  • Seams: RF welded / temperature resistance -30 °C / +70 °C
  • Factory warranty: 3 years recreational / 2 year commercial
  • Performance Tubes - Speed & stability (Optional)
  • Chambers 5 - Inflation and over inflation (One per chamber)
  • Self-bailers (1) *optional High flow scupper can be added
Standard Features:
  • Non-skid aluminum floor with anodized aluminum stringers
  • Marine plywood transom, epoxy coated
  • Transom splash guards
  • Aluminum engine mounting plate
  • Reinforcement on tube transom attachments
  • Standard pop-up self-bailers (internal release)
  • All around rub strake, flat profile, black
  • Rubbing strakes for beaching on keel and tubes
  • 10 carry handles, soft handle neoprene covered nylon
  • Bow handle (Stainless)
  • Exterior/Interior lifelines (Peripheral)
  • 11 Interior tie down D-rings (Stainless steel)
  • 2 large tow rings on bow (Stainless steel)
  • 4 large tow rings on rear tubes(Stainless steel)
  • Foot pump with hose & gauge (1) included
  • Repair kit (1) included
  • Storage bags, floor (1) hull (1)
  • Paddle set (Alum. shaft, plastic blade)
OUTBOARD
Specifications:
  • Horsepower: 40 HP
  • Drive Type: Remote Steering
  • Shaft Length: 20" (Long)
  • Starting: Electric Start
  • Gears: F - N - R
  • Weight: 229 lbs
  • Propeller Included: No
  • 3 Year Warranty
  • Power Trim and Tilt
Technical Specs
  • Model Name: DF40
  • Configuration: A
  • Horsepower: 40
  • Shaft Length (Inches): L (20)
  • Weight (Lbs): 229
  • Cylinders: In-line 3
  • Valves Per Cylinder: DOHC 4 Valves Per Cyl.
  • Valve Train Drive: Self adjusting oil bathed timing chain
  • Displacement: 57.4 cu. in. (941 cc)
  • Bore and Stroke (Inches/mm): 2.85 x 2.99 in. (72.5 x 76 mm)
  • Operating Range (RPM): 5000-6000
  • Induction System: Sequential EFI with Lean Burn Control
  • Starting System: Suzuki Easy Start System
  • Lubrication: Wet sump
  • Oil Tank Capacity: 2.9 qt. (2.7 lit.)
  • Ignition: Direct Ignition
  • Alternator: 12V 19A
  • Trim Type: Power Trim and Tilt
  • Gear Ratio: 2.27:1
  • CARB Emissions Rating: 3-Star Ultra-Low
  • Standard Propeller (Blades x Dia. x Pitches (Ins.)): Optional - See Dealer
  • Range of Avail. Optional Propeller Pitches: 9 - 17
  • Steering: Remote
